Up to 1.26 GHz Pentium® III processor with 256 KB advanced
transfer cache
• Up to 512 MB PC-133 SDRAM using a single SODIMM
• Internal AGP SVGA controller with 4 MB display cache
• 133 MHz system bus via Intel® 815E chipset
• Dual Ethernet controllers supporting 10BaseT and 100BaseTX
interfaces
• Optional PCI dual channel Ultra160 SCSI
• Up to three (two with rear I/O support) PMC expansion sites
(IEEE-P1386 common mezzanine card standard, 5 V)
• Up to 1 GB bootable flash on secondary IDE (optional)
• Two 16-bit and two 32-bit programmable timers
• 32 KB of nonvolatile SRAM
• Software-selectable watchdog timer with reset
• Remote Ethernet booting
• Optional IDE hard disk drive
• VME64 modes supported:
A32/A24/D32/D16/D08(EO)/MBLT64/BLT32
• VMEbus interrupt handler, interrupter and system controller
• Includes real time endian conversion hardware for littleendian
and big-endian data interfacing (patent no. 6,032,212)
• Enhanced bus error handling
• Passive heat sink
• Ultra DMA/100 hard drive and floppy drive controllers (uses
VMEbus P2 for external connection to primary channel
IDE/floppy)
• Two high performance 16550-compatible serial ports
• Enhanced parallel port with ECP/EPP modes supported
• PS/2-style keyboard and mouse ports on front panel
• Real time clock and miniature speaker included
• Dual front panel univeral serial bus (USB) connections
• Operating system support for Windows® XP, Windows 2000,
VxWorks®, Solaris x86, QNX®, LynxOS®, Linux®
