IPMC712
The MVME712M transition module provides industry-stan- dard connector access to the Centronics® parallel port, a nar- row SCSI port, and four DB-25 connectors providing access to the asynchronous/synchronous serial ports jumper config- urable as EIA-232 DCE or DTE. A P2 adapter provides interface signals to the MVME712M transition module. The 3-row P2 adapter can be used for 8-bit SCSI.
To gain access to the additional user definable I/O pins pro- vided via the 5-row VME64 extension connector, a special P2 adapter board is available. This adapter panel replaces the traditional 3-row P2 adapter and extends its capability by pro- viding access to the PMC I/O pins.
